Crosswater Union 3 Outlet Landscape Concealed Thermostatic Shower Valve with Wheels - Brushed Black Chrome

No reviews yet - Write one

RRP £1,474.00 save 25%


Estimated delivery 3-7 working days Help?

Too long to wait? View similar products with next day shipping

FREE standard delivery*. Read full delivery info

What's great about it?

  • 3 outlet concealed shower valve
  • Run each outlet individually or two simultaneously
  • Thermostatic temperature control
  • Minimum 1 bar water pressure required
  • 15 year guarantee

Read full product description

Recommended extras

We've hand-picked these items because they are a great choice alongside the Crosswater Union 3 Outlet Landscape Concealed Thermostatic Shower Valve with Wheels - Brushed Black Chrome

Crosswater Union 3 Outlet Landscape Concealed Thermostatic Shower Valve with Wheels - Brushed Black Chrome

• Eye-catching brushed black chrome finish with triple wheel control
• Thermostatic control keeps the temperature where you set it, even if the pressure fluctuates
• Pre-set maximum temperature of 42°C to prevent accidental scalding
• 3 outlet valve - ideal for use with a matching fixed shower head, Crosswater slide rail kit and body jets
• Run each outlet on their own or run two simultaneously
• Landscape orientation only
• Minimum 1 bar water pressure required to run 1 outlet on its own
• Minimum 2 bar water pressure required to run 2 outlets simultaneously
• 15 year guarantee from Crosswater
Product Code UB3001RB
Type Concealed Shower Valves
Global Trade Item Number 5055833686421
Brand Crosswater
Brand Range Crosswater Union
Number of OutletsMore information 3 Outlets
Shape Rectangular
Finish Brushed Black Chrome
Style Modern
Minimum Water PressureMore information 1
GuaranteeMore information 15 Years
Orientation Landscape
Handle Type Wheel, Triple Control
Temperature Control Thermostatic
Flow Rate at 0.2 Bar (l/min) 7.6
Flow Rate at 0.5 Bar (l/min) 13.1
Flow Rate at 1 Bar (l/min) 15.7
Flow Rate at 2 Bar (l/min) 21.9
Flow Rate at 3 Bar (l/min) 26.5

This indicates how many water outlets you can pair with your shower valves. Choosing valves with more outlets will give you flexibility over the number of products you can add to your shower.

Each outlet from your shower valve will divert water to the section of your shower that needs it, so each extra outlet allows you to add another product. For example: with 1 outlet you could have just a fixed shower head. 2 outlets will allow you to have a fixed shower head and shower handset. 3 will allow both of these with the addition of a body jet.

Your water pressure depends on your home's water system. It’s important to consider water pressure when buying a new tap or shower. Buying a product with a minimum water pressure that’s too high for your home will result in poor performance.

- With a combi boiler you can usually expect between 1 and 2 bar

- With a gravity system (cold water tank in attic) you may have as little as 0.1 or 0.2 bar upstairs, and perhaps 0.5 bar downstairs

- With a high pressure unvented system (hot water cylinder, no cold water tank) you will generally have between 1 and 3 bar

You can install an item with a low minimum pressure rating on a high pressure system, but avoid installing an item with a high minimum rating on a low pressure system! Read our guide to water pressure to learn more.


Please note that these guarantees are provided by the manufacturer, and will be subject to individual terms and conditions, for example avoiding abrasive bleach-based cleaning products.

If you need further info about a specific manufacturer's guarantee, please contact our team.
