Hudson Reed Revolution Industrial Basin Mixer Tap & Waste

No reviews yet - Write one

RRP £282 save 52%

£134.99

Loading delivery estimate...

Klarna
Pay 3 interest-free instalments of £44.99 with Klarna Learn more about Klarna
Clearpay
Pay 4 interest-free instalments of £33.75 with Clearpay Learn more about Clearpay

What's great about it?

  • Monobloc basin mixer
  • Chrome finish with brass construction
  • Minimum water pressure 0.2 bar
  • Waste included
  • 20 year manufacturers guarantee

Read full product description

Recommended extras

We've hand-picked these items because they are a great choice alongside the Hudson Reed Revolution Industrial Basin Mixer Tap & Waste

Features:
  • Mono basin mixer
  • Unique industrial design
  • Chrome finish with brass internal
  • Ceramic disc (1/4 turn)
  • Wheel control
  • Deck mounted
  • Waste included
  • Minimum water pressure of 0.2 bar
  • 20 year manufacturer's guarantee

Dimensions:
  • Height: 219mm
  • Width: 216mm
  • Depth: 172mm
  • Projection: 134mm

Product Overview
Product Code TIW315
Global Trade Item Number 5056211854999
Type Basin Mixer Taps
Brand Hudson Reed
Brand Range Hudson Reed Revolution
GuaranteeMore information 20 Years

Guarantee

Please note that these guarantees are provided by the manufacturer, and will be subject to individual exclusions, exceptions, and terms and conditions, for example avoiding abrasive bleach-based cleaning products.

If you need further info about a specific manufacturer's guarantee, please contact our team.

Features
Cartridge TypeMore information Ceramic Disc
Waste TypeMore information Push Button
Material Brass

Taps use either a ceramic disc cartridge or a rubber compression washer to control flow. Rubber washers will naturally wear down with use, and the tap handle will require more and more rotations to turn on or off. On the plus side, it's very easy to replace a rubber washer and they're available everywhere.

Ceramic disc cartridges need only a 90-degree rotation to fully open or close, and the 2 ceramic plates are incredibly hard-wearing and resilient. They're more expensive to make, but they allow for a huge range of designs, easy operation and simple maintenance if needed.

Whilst it is rare for a ceramic cartridge to need replacing, you may very occasionally need to remove and rinse the cartridge if grit or debris within the water system is preventing the 2 plates from closing properly. Much like replacing a rubber washer, this is a quick and easy job, and will ensure many years of use.

The waste in your basin will allow the water in your sink to safely flow down the drain. There are two main types of waste available: slotted & unslotted.

If your basin has an overflow you will need a slotted waste. If your basin doesn’t have an overflow, you will need an unslotted waste.

For a full explanation of the types of basin waste available, take a look at our comprehensive guide.

Style
Shape Curved
Mounting Type Deck Mounted
Finish Texture Polished
Finish Chrome
Style Modern
Tap Holes Mono
Handle Type Dual Control, Round
Spout TypeMore information Swan Neck Spout

Tap spouts are available in a variety of different styles which have an effect on both the look and function of your tap. Different spout types will have different heights and projections, so it’s important to choose one which will complement your basin or bath.

Dimensions
Width (mm) 216
Height (mm) 219
Depth (mm) 172
Projection (mm) 134
Flow Rate
Flow Rate at 0.5 Bar (l/min) 16
Flow Rate at 1 Bar (l/min) 22
Flow Rate at 2 Bar (l/min) 31
Flow Rate at 3 Bar (l/min) 38
Minimum Water PressureMore information 0.2

Your water pressure depends on your home's water system. It’s important to consider water pressure when buying a new tap or shower. Buying a product with a minimum water pressure that’s too high for your home will result in poor performance.

- With a combi boiler you can usually expect between 1 and 2 bar

- With a gravity system (cold water tank in attic) you may have as little as 0.1 or 0.2 bar upstairs, and perhaps 0.5 bar downstairs

- With a high pressure unvented system (hot water cylinder, no cold water tank) you will generally have between 1 and 3 bar

You can install an item with a low minimum pressure rating on a high pressure system, but avoid installing an item with a high minimum rating on a low pressure system! Read our guide to water pressure to learn more.
