Upgrade your bathroom with the Vellamo Echo Slide Rail Kit featuring a modern design and a practical 3-Mode Handset. Effortlessly switch between spray options for a personalised shower experience.
- Includes a stainless steel 650mm rail, adjustable brass handset holder, ABS 3-mode shower handset, and a smooth PVC 1.5m shower hose
- Minimum operating pressure: 0.5 bar
- Handset height adjustment via single-motion sliding mechanism with twist-lock functionality
- 650mm Stainless steel rail offering durability for long term use
- High-quality adjustable brass handset holder
- 3 mode shower handset, offering saturating, massage, and combined spray functions for a customised shower experience
- Easy clean nozzles for effortless cleaning, simply rub away any limescale deposits
- Featuring a 1.5m smooth PVC construction, the hose is designed to resist buildup and allow for easy, hassle-free cleaning
- Outlet elbow and shower valve sold separately, please see our recommended extras
Product Code | VELECHO04 |
---|---|
Type | Shower Rail Kits |
Brand | Vellamo |
Brand Range | Vellamo Echo |
Number of OutletsMore information | 1 Outlet |
---|---|
Popular Features | Easy Clean Nozzles, Multifunction Water Flow |
Material | ABS Plastic, Brass, PVC, Stainless Steel |
This indicates how many water outlets you can pair with your shower valves. Choosing valves with more outlets will give you flexibility over the number of products you can add to your shower.
Each outlet from your shower valve will divert water to the section of your shower that needs it, so each extra outlet allows you to add another product. For example: with 1 outlet you could have just a fixed shower head. 2 outlets will allow you to have a fixed shower head and shower handset. 3 will allow both of these with the addition of a body jet.
Shape | Round |
---|---|
Mounting Type | Wall Mounted |
Finish Texture | Polished |
Finish | Chrome |
Style | Modern |
Hose Length (mm) | 1500 |
---|---|
Width (mm) | 114 |
Height (mm) | 650 |
Depth (mm) | 69 |
Projection (mm) | 69 |
Flow Rate at 0.5 Bar (l/min) | 8 |
---|---|
Flow Rate at 1 Bar (l/min) | 10.9 |
Flow Rate at 1.5 Bar (l/min) | 13.3 |
Flow Rate at 2 Bar (l/min) | 15.5 |
Flow Rate at 3 Bar (l/min) | 19.4 |
Flow Rate at 4 Bar (l/min) | 24.9 |
Minimum Water PressureMore information | 0.5 |
Your water pressure depends on your home's water system. It’s important to consider water pressure when buying a new tap or shower. Buying a product with a minimum water pressure that’s too high for your home will result in poor performance.
- With a combi boiler you can usually expect between 1 and 2 bar
- With a gravity system (cold water tank in attic) you may have as little as 0.1 or 0.2 bar upstairs, and perhaps 0.5 bar downstairs
- With a high pressure unvented system (hot water cylinder, no cold water tank) you will generally have between 1 and 3 bar
You can install an item with a low minimum pressure rating on a high pressure system, but avoid installing an item with a high minimum rating on a low pressure system! Read our guide to water pressure to learn more.
