Crosswater Belgravia Wall Mounted Bath Spout with Crosshead Valves

Rated 5.00/5 from 2 customer reviews

RRP £454 save 28%

£328.99

Loading delivery estimate...

Klarna
Pay 3 interest-free instalments of £109.66 with Klarna Learn more about Klarna
Clearpay
Pay 4 interest-free instalments of £82.25 with Clearpay Learn more about Clearpay

What's great about it?

  • Beautifully designed bath spout with crosshead controls
  • Authentically traditional wide opening spout to pour water elegantly into your bath
  • Glistening chrome plated finish
  • 15 year manufacturers guarantee

Read full product description

Recommended extras

We've hand-picked these items because they are a great choice alongside the Crosswater Belgravia Wall Mounted Bath Spout with Crosshead Valves

Modern sophisticated design with hints of classical styling, the Belgravia Crosshead Wall Mounted Bath Spout with Wall Stop Taps by Crosswater will no doubt help transform your bathroom into a minimalist, traditional sanctuary you'll never want to leave. Mounted on your wall over your bath, the spout will elegantly pour water into your bath thanks to the authentic wide opening. You'll also receive two wall stop taps for you to control the temperature and flow of water. With decorative branded ceramic heads and ball ended spokes, these valves add a sense of authenticity to the look you want to achieve. And with modern Ceramic disc technology tucked away inside, you'll only need a smooth quarter-turn to turn on and off whilst they also prevent excess dripping and leaking thanks to their durability.

Expertly crafted from solid Brass, your new bath tap comes with a gorgeous Chrome plated finish and is supplied with a 15 year manufacturers guarantee as standard. So you can unwind in your luxury freestanding bath with peace of mind your new spout has been built to last.

Features:
  • Suitable for high pressure systems only - minimum 1.0 bar water pressure is recommended
  • Ceramic disc technology for smooth operation and no excess dripping or leaking once turned off
  • Made from Brass with a Chrome plated finish
  • Waste is sold separately
  • 15 year manufacturers guarantee

Dimensions:
  • Projection: 176mm

Product Overview
Product Code crosswater-bel-lvr-wm-bath-spout
Global Trade Item Number 5055833618927
Type Bath Spouts
Brand Crosswater
Brand Range Crosswater Belgravia Crosshead
GuaranteeMore information 15 Years

Guarantee

Please note that these guarantees are provided by the manufacturer, and will be subject to individual terms and conditions, for example avoiding abrasive bleach-based cleaning products.

If you need further info about a specific manufacturer's guarantee, please contact our team.

Features
Cartridge TypeMore information Ceramic Disc
Number of OutletsMore information 1 Outlet
Material Brass
Temperature Control Manual

Taps use either a ceramic disc cartridge or a rubber compression washer to control flow. Rubber washers will naturally wear down with use, and the tap handle will require more and more rotations to turn on or off. On the plus side, it's very easy to replace a rubber washer and they're available everywhere.

Ceramic disc cartridges need only a 90-degree rotation to fully open or close, and the 2 ceramic plates are incredibly hard-wearing and resilient. They're more expensive to make, but they allow for a huge range of designs, easy operation and simple maintenance if needed.

Whilst it is rare for a ceramic cartridge to need replacing, you may very occasionally need to remove and rinse the cartridge if grit or debris within the water system is preventing the 2 plates from closing properly. Much like replacing a rubber washer, this is a quick and easy job, and will ensure many years of use.

This indicates how many water outlets you can pair with your shower valves. Choosing valves with more outlets will give you flexibility over the number of products you can add to your shower.

Each outlet from your shower valve will divert water to the section of your shower that needs it, so each extra outlet allows you to add another product. For example: with 1 outlet you could have just a fixed shower head. 2 outlets will allow you to have a fixed shower head and shower handset. 3 will allow both of these with the addition of a body jet.

Style
Shape Round
Mounting Type Wall Mounted
Finish Texture Polished
Finish Chrome
Style Traditional
Tap Holes 3 Holes
Handle Type Crosshead, Dual Control
Spout TypeMore information Curved Spout

Tap spouts are available in a variety of different styles which have an effect on both the look and function of your tap. Different spout types will have different heights and projections, so it’s important to choose one which will complement your basin or bath.

Dimensions
Projection (mm) 176
Flow Rate
Minimum Water PressureMore information 1

Your water pressure depends on your home's water system. It’s important to consider water pressure when buying a new tap or shower. Buying a product with a minimum water pressure that’s too high for your home will result in poor performance.

- With a combi boiler you can usually expect between 1 and 2 bar

- With a gravity system (cold water tank in attic) you may have as little as 0.1 or 0.2 bar upstairs, and perhaps 0.5 bar downstairs

- With a high pressure unvented system (hot water cylinder, no cold water tank) you will generally have between 1 and 3 bar

You can install an item with a low minimum pressure rating on a high pressure system, but avoid installing an item with a high minimum rating on a low pressure system! Read our guide to water pressure to learn more.
