Features:
- 160W per m2 electric underfloor heating mat for smooth, comfortable warmth underfoot
- Suitable for floor warming across the home, or full-room heating in well-insulated spaces
- Pre-spaced heating cable on a flexible mesh mat for a quicker, cleaner installation than loose cable
- Cut-and-turn design makes it easier to shape the mat around your room layout without cutting the heating cable
- Suitable for direct installation beneath tile and stone floors
- Can be used beneath a wide range of other floor coverings when first covered with a 12mm layer of flexible levelling compound
- Works with floor-limiting thermostats to help protect more sensitive floor finishes
- Low-profile design with an approximate 4mm build height
- 0.5m mat width helps create neat, even runs across the floor
- Multiple mats can be used together for larger rooms, provided they have the same wattage output per m2
- Anti-crush cable jacket and 100% earth shield offer added reassurance beneath the surface
- 2.5m coldtail included for connection to a compatible thermostat
- Pair with the Toasty Programmable Thermostat Controller or Toasty WiFi Thermostat Controller for easy heating control
- UKCA marked and tested to BS/EN60335-2-96
- 20 year guarantee
 Installation Instructions
|
|---|
| Product Code | toasty-elec-ufh-160W/sqm-pv |
|---|---|
| Type | Underfloor Heating Mat Sets |
| Brand | Toasty |
| Guarantee |
20 Years |
| Global Trade Item Number | Select an option first |
Guarantee
Please note that these guarantees are provided by the manufacturer, and will be subject to individual exclusions, exceptions, and terms and conditions, for example avoiding abrasive bleach-based cleaning products.
If you need further info about a specific manufacturer's guarantee, please contact our team.
| IP Rating |
IPX7 |
|---|---|
| Voltage (V) |
230 |
| Material | Copper, PVC |
| Temperature Control | Thermostatic |
IP stands for ingress protection. It is a measure of the effectiveness of sealing electrical enclosures from foreign bodies such as tools and water.
IP ratings are given in two digits:
1st digit: A number between 0-6 which gives an indication of the protection from solid objects such as tools, dirt and dust. The higher the number, the better the protection.
2nd digit: A number 0-9 which indicates the protection of the electrical enclosures from moisture ingress. The higher the number, the better the protection against moisture.
If you see an X instead of a number (e.g., IPX7 or IP6X), it means the product has not been officially tested for that specific category, as it may not be applicable.
This is what makes electric charges move. It’s the ‘push’ that causes electricity to move through a product. It’s important to choose low-voltage products for use in your bathroom to ensure they operate safely. For more information on voltage in bathroom zones read our article.
| Mounting Type | Underfloor |
|---|
| Width (mm) | 500 |
|---|---|
| Height (mm) | 4 |
| Cable Thickness (mm) | 4 |
| Cold Tail Length (mm) |
2500 |
| Area (sq. m) | Select an option first |
| Length (mm) | Select an option first |
Cold Tail Length (mm)
The non-heating cable that connects your system to the power supply.
The length shows how far it can reach to your connection point — with longer lengths giving you more flexibility during installation, without the need for extra wiring.
| Fuel Source |
Electric |
|---|---|
| Heat Output (BTU∆t 50ºC) | Select an option first |
| Heat Output (Watts∆t 50ºC) | Select an option first |
This is the source of fuel your radiator or towel rail will use to provide heat. Radiators will generate heat through central heating systems, electricity, or a combination of both with dual fuel.
Central Heating:
These radiators will generate heat through the water pumped round your central heating system.
Electric:
Electric radiators contain fluid heated by an electrical element. They plug into a socket or are wired directly into the mains.
Dual Fuel:
Dual fuel radiators are able to run on both central heating and electric power. They contain a ‘summer’ heating element which will allow you to use your radiator in warmer months without needing to turn on your entire central heating system.
