Recommended extras
Hand-picked recommendations to go alongside this product
The most popular of the mat set’s Thermogroup offer, this one is incredibly versatile and will only cost between £12 - £14 per m², per year in running costs.
Built with safety in mind, the cables have a tough fluoropolymer coating on the outside as well as the internal conductors, a continuous armoured earth sheath and multi strand twin conductors. It’s also got a twisted, multi strand earth braid across the entire length of the cable.
Easy to install on both concrete and timber substrates, Thermonet has Layflat technology which makes it quicker to install with less hassle. The self-adhesive fibreglass mesh sticks to your substrate and stops it floating in levelling compound or rising up through tile adhesive. It also features a low profile cold tail connection that’s the thinnest on the market and has been designed to allow you to lay the matting flat to the floor, even when you need to curve it around corners. It’s also recommended that you lay this matting on insulation boards to prevent downwards heat loss and maximise the efficiency of your heating. You’ll need coated insulation boards for timber substrates and uncoated for concrete substrates.
You can use this product under carpet, laminate, wooden or tiled flooring. For installation under carpet, laminate or wooden flooring, simply use a layer of self-levelling compound over the top of the matting, for tiled flooring you’ll need to use a layer of flexible tile adhesive (sold separately).
With a single connection cable and the ability to wire multiple mats in parallel to a single thermostat (up to 3600W & sold separately), there’s no need to chisel out your substrate, and you can also install within the adhesive layer of a tiled floor without the need for levelling compound or raising the floor level.
Features:
Additional information:
Heat up times:
Size & output information:
1m²: 2 x 0.5m 150W output
1.5m²: 3 x 0.5m 225W output
2m²: 4 x 0.5m 300W output
2.5m²: 5 x 0.5m 375W output
3m²: 6 x 0.5m 450W output
3.5m²: 7 x 0.5m 525W output
4m²: 8 x 0.5m 600W output
4.5m²: 9 x 0.5m 675W output
5m²: 10 x 0.5m 750W output
6m²: 12 x 0.5m 900W output
7m²: 14 x 0.5m 1050W output
8m²: 16 x 0.5m 1200W output
9m²: 18 x 0.5m 1350W output
10m²: 20 x 0.5m 1500W output
12m²: 24 x 0.5m 1800W output
14m²: 28 x 0.5m 2100W output
16m²: 32 x 0.5m 2400W output
Built with safety in mind, the cables have a tough fluoropolymer coating on the outside as well as the internal conductors, a continuous armoured earth sheath and multi strand twin conductors. It’s also got a twisted, multi strand earth braid across the entire length of the cable.
Easy to install on both concrete and timber substrates, Thermonet has Layflat technology which makes it quicker to install with less hassle. The self-adhesive fibreglass mesh sticks to your substrate and stops it floating in levelling compound or rising up through tile adhesive. It also features a low profile cold tail connection that’s the thinnest on the market and has been designed to allow you to lay the matting flat to the floor, even when you need to curve it around corners. It’s also recommended that you lay this matting on insulation boards to prevent downwards heat loss and maximise the efficiency of your heating. You’ll need coated insulation boards for timber substrates and uncoated for concrete substrates.
You can use this product under carpet, laminate, wooden or tiled flooring. For installation under carpet, laminate or wooden flooring, simply use a layer of self-levelling compound over the top of the matting, for tiled flooring you’ll need to use a layer of flexible tile adhesive (sold separately).
With a single connection cable and the ability to wire multiple mats in parallel to a single thermostat (up to 3600W & sold separately), there’s no need to chisel out your substrate, and you can also install within the adhesive layer of a tiled floor without the need for levelling compound or raising the floor level.
Features:
- Comes with: Thermonet self adhesive mat, factory test certificate & an installation guide
- 150W/m² matting is designed for using as a primary heat source in well insulated areas with coverage of at least 80% of the floor
- High grab self-adhesive mesh made from high quality fiberglass
- Cables are only 3.5mm thick
- Incredibly energy efficient and safe to use in wet areas
- If installing on concrete substrates it’s recommended to use an uncoated insulation board
- If installing on timber substrates it’s recommended to use a coated insulation board
- Lifetime manufacturers guarantee
Additional information:
- Width: W500mm (430mm heated)
- Maximum thickness: 3.5mm
- Output: 150W/m2
- Maximum operating temperature: 29C
Heat up times:
- Concrete & 50mm Econoboard: 30 minutes
- Concrete & 10mm Econoboard: 1 hour
- Un-insulated concrete: 5 hours
- Concrete & sub surface insulation: 3 hours
- Chipboard & 10mm Econoboard: 30 minutes
- Un-insulated chipboard: 1 hour
Size & output information:
1m²: 2 x 0.5m 150W output
1.5m²: 3 x 0.5m 225W output
2m²: 4 x 0.5m 300W output
2.5m²: 5 x 0.5m 375W output
3m²: 6 x 0.5m 450W output
3.5m²: 7 x 0.5m 525W output
4m²: 8 x 0.5m 600W output
4.5m²: 9 x 0.5m 675W output
5m²: 10 x 0.5m 750W output
6m²: 12 x 0.5m 900W output
7m²: 14 x 0.5m 1050W output
8m²: 16 x 0.5m 1200W output
9m²: 18 x 0.5m 1350W output
10m²: 20 x 0.5m 1500W output
12m²: 24 x 0.5m 1800W output
14m²: 28 x 0.5m 2100W output
16m²: 32 x 0.5m 2400W output
Product Code | Thermonet-EZ-150 |
---|---|
Type | Underfloor Heating Mat Sets |
Brand | ThermoSphere |
Brand Range | ThermoSphere Underfloor Heating |
GuaranteeMore information | Lifetime |
Guarantee
Please note that these guarantees are provided by the manufacturer, and will be subject to individual exclusions, exceptions, and terms and conditions, for example avoiding abrasive bleach-based cleaning products.
If you need further info about a specific manufacturer's guarantee, please contact our team.
Style | Modern |
---|
Width (mm) | 500 |
---|---|
Area (sq. m) | Select an option first |
Fuel SourceMore information | Electric |
---|---|
Heat Output (Watts) | Select an option first |
This is the source of fuel your radiator or towel rail will use to provide heat. Radiators will generate heat through central heating systems, electricity, or a combination of both with dual fuel.
Central Heating:
These radiators will generate heat through the water pumped round your central heating system.
Electric:
Electric radiators contain fluid heated by an electrical element. They plug into a socket or are wired directly into the mains.
Dual Fuel:
Dual fuel radiators are able to run on both central heating and electric power. They contain a ‘summer’ heating element which will allow you to use your radiator in warmer months without needing to turn on your entire central heating system.
